Ortofon MC Windfeld Ti

MC Cartridge with Nude Ortofon Repl. Diamond 100

£4,399.00

Add to Cart

Ortofon MC Windfeld Ti £4,399.00

The MC Windfeld Ti replaces the original MC Windfeld in Ortofon’s Exclusive Series of products, providing a series of improvements that enhance the technical and sound performance abilities of this popular high-end offering.

The MC Windfeld Ti is a moving coil (MC) phono cartridge built into a new and improved cartridge body. Sharing obvious similarities with the high-end Cadenza Series, the central band of the MC Windfeld Ti body is made using a revolutionary Selective Laser Melting (SLM) manufacturing technology, also used by Ortofon on the flagship MC Anna cartridge. The technology uses Titanium to increase the overall rigidity of the cartridge body, eliminating unwanted vibrations within the cartridge and increasing the dynamic capability.

Inside the MC Windfeld Ti, Ortofon employ a series of advanced technologies – many developed entirely in-house – to deliver a true high-end performance.

Like the flagship MC Anna cartridge, the MC Windfeld Ti makes use of “the finest diamond in the world”. The Ortofon Replicant 100 boasts a thin and light profile with an impressively long vertical contact surface, making it as close as possible to an original record cutting stylus. By specially polishing the stylus and then mounting it onto a boron cantilever, the cartridge can offer remarkable transparency, speed, and responsiveness beyond that of any other combination.

The stylus and cantilever are connected into a compact, lightweight generator system based around a powerful neodymium magnet and Ortofon’s Aucurum 6NX oxygen-free copper coil wire. The specially designed armature used inside the system has low magnetic properties for uninhibited tracking of the cantilever’s movements. An additional Field-Stabilizing Element (FSE) is also placed inside the system to prevent the magnetic field from fluctuating, which allows for improved channel separation, zero transmission loss and greater sound-staging with more space between the performers.

The cantilever also passes through a suspension system aided by Ortofon’s Wide Range Damping (WRD) system, in which a small, heavy platinum disc is sandwiched between two rubber absorbers with different properties for exceptional tracking performance and perfect damping throughout the frequency range. The result is a distortion-free performance with an exceptionally linear frequency response.

Specifications

Warranty

1 Year
